Section 03-00: Engine, Service | 1996 All F-150, F-250, F-350, F-Super Duty and Bronco Vehicles Equipped with 4.9L, 5.0L, 5.8L or 7.5L Gasoline Engines, and 7.3L Diesel Engines Workshop Manual |
For quick engine identification, refer to the Vehicle Emission Control Information (VECI) Decal mounted under the hood (16612). This decal lists engine information required for proper servicing of the engine (6007). Refer to Section 00-03 for further information. An engine identification label is also attached to the engine. The symbol code on the identification tag identifies each engine for determining parts usage, for instance, engine displacement and model year. Engine decal information is located in Section 03-01A (4.9L SFI), Section 03-01B (5.0L and 5.8L MFI), Section 03-01C (7.5L MFI) or Section 03-01D (7.3L diesel).
The vehicle identification number (VIN) also gives engine information. The tenth digit identifies the engine. Refer to Section 00-01 for further information.
Emission Calibration Number Label
The emission calibration number label is located on the left side door or left door post pillar. It identifies the engine calibration number, the engine code number and revision level.
